WEIAND X-CELERATOR INTAKE – FORD SMALL BLOCK V8 – 351C
X-CELerator Intake Manifold for Ford 351 Cleveland V8 2V Head
Part # 7516
The WEIAND X-CELerator™ SERIES: 360°, single-plane, open plenum manifold designed primarily for high-performance street, drag, marine and oval track use. With an effective rpm range of 2000 to 6500 rpm, this series works best with a higher compression ratio, 280° or more of cam duration and headers with 1-5/8″ primary tubes. Being a mid- to high-rpm manifold, a standard transmission, or an automatic transmission with a 3000 rpm stall converter, is highly recommended. The carburetor mounting pad is designed to accept current performance aftermarket carburetors. The WEIAND X-CELerator Series is the ultimate street/strip performance manifold for single 4V applications where increased torque and power is required in the mid and high rpm ranges.
Features:
- Single Plane Design
- Square Carburetor Mounting Flange
- Power band: 1500-7000 RPM
- Height: Front 4.28″, Rear 5.36″
- Port Size: 1.95” height 1.34″ width
- No EGR provision
- New updated casting design
Brand | Weiand |
---|---|
Construction | Cast |
Emission Code | 3 |
Engine | Ford Cleveland |
Finish | Satin |
Front Height | 4.28 inch |
Fuel System Type | Carb |
Manifold Type | Low Rise |
Product Type | Intake Manifold |
Rear Height | 5.36 inch |
RPM Power Band | 1500-7000 |
Warranty | Limited 90 Day |
UPC | 032474751607 |
Part Number | 7516 |
