QUICK TIME
QUICKTIME BELLHOUSING – CHEVY LS AND LATE MODEL LT – LOW PROFILE
Designed to fit Gen 3 and 4 LS and Late Model LT1/4 (2014-Current) Engines utilizing an LS T-56 Transmission
Part # RM-8019
The Quick Time RM-8019 bellhousing connects Gen 3 and 4 LS and Late Model LT1/4 (2014 – Current) engines to T-56 Chevy LS, and T56 Magnum transmissions. This bellhousing is a universal fit bellhousing and is not vehicle specific. The Quick Time bellhousings are produced using a unique spin-forming process which results in a very high-strength material. This high material strength allows the Quick Time bellhousings to be lightweight while maintaining the protection you desire. Note: (Transmission Mounting Bolts Not Included)
Features:
- Quick Time Bellhousings are the most accurate bellhousings available due to our unique manufacturing processes
- QuickTime cones are spun, not rolled or stamped. This allows Quick Time Bellhousings to be the most dimensionally stable Bellhousings available
- Built from high grade steel – Work hardens to over 80,000 PSI strength. Over two times the strength of other steel bellhousings
- 100% built in the USA
- Patent on 16 points of Bellhousing Design & Process
| Brand | Quick Time |
|---|---|
| Certification | None |
| Clutch Operation | Hydraulic |
| Color | Black |
| Emission Code | 5 |
| Engine | Chevy LT1 |
| Chevy LT4 | |
| GM Gen III/IV (LS) | |
| Engine Make | Chevrolet |
| Engine Plate | RM-6034-C |
| Finish | Semi-gloss |
| Flywheel | 168 Tooth |
| Height | 5.500 inch |
| Height (in) | 5.5 |
| Make | Chevrolet |
| Material | Steel |
| Patented | yes |
| Product Type | Bellhousing |
| Sale Category | Transmission and Drivetrain |
| SFI Approved | No |
| Trans Bore | N/A |
| Trans. Bore Diameter | N/A |
| Transmission | T56 GM |
| T56 Magnum | |
| Transmission Type | Manual |
| Warranty | Limited 90 Day Warranty |
| Weight | 20# |
| Weight (lb) | 20 |
| UPC | 090127030509 |
| Part Number | RM-8019 |
