Holley EFI Fuel Tank Module – 255 LPH 1968-1972 GM A-Body Vehicles
In-tank fuel pump module for 1968-1972 Chevelle, Malibu & El Camino. Supports Up To 550 Horsepower.
Part # 12-303
This in-tank fuel pump module is a high-pressure unit that flows 255 liters per hour (LPH) and is capable of supporting electronic fuel injection (EFI) engines producing up to 550 horsepower. A pre-calibrated fuel-level sending unit designed to work with the factory fuel gauge for this application is included. This module also features a HydraMat filter which has a unique internal reservoir that keeps fuel available at the pick-up and also provides protection from contaminates The fuel pressure is internally regulated to 58 psi eliminating the added expense and effort of purchasing and installing an external fuel pressure regulator – no separate return line is required because this module returns excess fuel right inside the tank! This 1968-1972 GM A-body Muscle Car EFI Fuel Pump module was designed as a direct replacement for your factory pick-up and sending unit. There is no need to purchase a custom EFI fuel tank. You can even retain the factory fuel hard line – just connect the outlet of the pump module to the hard line on your vehicle with EFI-rated fuel hose and hose clamps available in the Earls Vapor Guard line. This Muscle Car EFI Module includes a 255 LPH fuel pump and a Holley HydraMat. HydraMat is an amazing patent-pending fuel reservoir system that reduces fuel starvation issues that might otherwise occur while cornering, accelerating, stopping, traversing inclines, and during low fuel conditions.
Features:
- Supports up to 550 horsepower (HP)
- Flows 255 liters per hour (LPH)
- Internally regulated to 58 PSI
- Included HydraMat patent-pending fuel reservoir system that reduces fuel starvation issues
| Application | 1968-1972 GM A-Body |
|---|---|
| Average Flow Rating | 255 LPH |
| Brand | Holley Sniper EFI |
| Category | Air and Fuel Delivery |
| Connector Gender | Male |
| Emission Code | 5 |
| Free Flow LPH | 255 |
| Fuel Filter Included | Yes |
| Fuel Sending Unit Included | Yes |
| Fuel Sending Unit Ohms | 0-90 Ohms |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | Gasoline |
| Gasket Or Seal Included | Yes |
| Grade Type | Performance |
| In Tank or External | In Tank |
| Inlet Diameter (in) | 5/16 |
| Inlet Quantity | One |
| Lock Ring Included | Yes |
| Material | Steel |
| Maximum Pressure | 58 PS |
| Negative Ground | Yes |
| Outlet Outside Diameter | 3/8 IN |
| Outlet Quantity | One |
| Part Type | Fuel Pump Module Assembly |
| Product Type | Fuel Pump Module |
| Pump Type | Electric |
| Regulator Included | Yes |
| Resistance Ohms Empty | 0 82 |
| Resistance Ohms Full | 90 82 |
| Strainer Included | Yes |
| Sub Category | Fuel Pumps and Related Components |
| Universal Or Specific Fit | Specific |
| Vent Size | N/A |
| Warranty | Limited 90 Day |
| Wire Harness Included | Yes |
| UPC | 090127029046 |
| Part Number | 12-303 |
