Features:

• Seamlessly integrates with your 7.3-liter Ford Godzilla engine for easy installation
• No need for extensive modifications; enjoy a hassle-free setup
• Base Calibrations included in the free Terminator X Software, and Handheld Wizard – OEM VVT and Oil pump control pre-configured
• Godzilla Crank Sensor Module included, must be used in-line with factory crank sensor
• OEM Oil pump control and VVT Control built into both Godzilla main harnesses, these features utilize 2 inputs and are pre-configured in the base calibrations.
• Customizable tuning parameters allow you to tailor performance to your specific driving preferences.
• Drive-by-wire kits require the use of the specific OEM throttle bodies and throttle pedals: Throttle Body – JL3E-9F991-AA – Throttle Pedal – BR3Z-9F836-D. Other options are listed within instruction manual 199R12525
• Real-Time fuel map learn, takes the guess work out of tuning your base fuel table.
• High Impedance Injector Drivers will safely power most OEM injectors, and Holley EFI Injectors. (Will not control Low Impedance Injectors)
• All of the new Terminator X Max systems utilize the Bosch LSU 4.9 wideband to relay AFR information to the ECU for accurate reading and precise tuning control.
• On-Board 1BAR MAP sensor, is perfect for N/A or Nitrous engine combos. If your combination requires a 2+BAR, we recommend GM 12592525, and our adapter part number 558-416.
• MAP Sensor vacuum hose adapters (1/8th – ¼ and 3/16ths)
• 4 Inputs – 12v, Ground, 5v, and Frequency, for things such as additional pressure sensors, or activation triggers for nitrous activation, or a trans brake
• 4 Outputs – Ground, PWM – , for accessories such as; fans, boost control, nitrous control, IAC Kit, and More
• Boost Control – Boost vs Time, Boost vs Gear, Boost vs RPM, Boost vs Speed, Boost Safeties
• Nitrous Control – Single Channel of Wet or Dry, Progressive or Non-Progressive, Rich/Lean Safeties, and target Closed Loop AFR
• Advanced Tables – 4x 1D Tables, 1x 1D per Gear Table, 4x 2D Tables, 1x 2D per Gear Table, can be used for any custom tables you can dream up, such as Flex Fuel Sensor Offset Table, or a custom fuel or oil pressure safety!
• On-Board Diagnostic LEDS for: ECU Power – Engine Run – Wideband Status – TPS Calibration – Crank Signal –Cam Signal. Allow you to identify any Critical engine issues at a glance
• The included 3.5-inch Touchscreen Handheld contains a calibration wizard, that allows you to quickly build a base tune for any Godzilla engine. Additionally, the handheld provides internal data-logging and a fully customizable gauge display.
• The compact ECU size allows you to mount it virtually anywhere. Remember, diagnostic LEDS must face up!
• Plug and play compatible with more Holley EFI accessories such as; analog style gauges, EGT module, aswell as 5-inch, 6.86-inch and 12.3-inch Digital Dashes
• Free EFI Tuning Software for complete control of your Terminator X power plant
