B&M
B&M HI-TEK HEAVY-DUTY DEEP TRANSMISSION PAN – FORD 10R80 – ALUMINUM – Silver
Fits 2017-2023 Ford F-150, Expedition, Explorer, Bronco, Ranger, and Lincoln Navigator, Aviator with 10R80 or 10R60 Transmissions
Part # 70400
Our Hi-Tek deep transmission pans are constructed from A356-T6 aluminum and are cast with thick internal and external fins, adding additional strength and increased cooling properties. The deep pan design increases fluid capacity by 2 quarts over the stock O.E. pan. All these features combined help dissipate heat quicker netting lower transmission and fluid temperatures and prolonging the life of your transmission, transmission fluid, and corresponding components. Other features of this popular pan include a drain port with a magnetic drain plug for clean and easy servicing. Also includes a 1/8-inch NPT temperature sensor port for easily adding a temp gauge for monitoring transmission temperatures while daily driving, towing, or racing. Includes detailed instructions with all necessary hardware for an easy at-home installation. Note: 10R80 transmissions do not come with a dipstick from the factory to check the fluid level. As a solution, B&M offers an optional locking dipstick part #22200 to measure transmission fluid level. Also available in a natural finish (B&M Part #70400).
Features:
- Drain Port with Magnetic Drain Plug for Easy Servicing
- Durable A356 Aluminum Construction
- Features a Temperature Sensor Port
- Includes Filter Extension
- Additional 2-Quart Fluid Capacity
- MIL-Spec Black Anodized Finish
- Lifetime Limited Warranty
- Over 65 Years of B&M Experience and Quality
- Increased Cooling Properties
- Hardware Included
- Easy Installation
Additional Fluid Capacity (qts) | 2 |
---|---|
Bolt Count | 21 |
Bolt/Studs Included | Yes |
Brand | B&M |
Color/Finish | Natural |
Drain Plug Included | Yes |
Drain Plug Type | Magnetic |
Emission Code | 5 |
Filler Plug Included | No |
Gasket Included | No |
Material | A356.0-T6 Aluminum |
Product Type | Automatic Transmission Pans |
Temp Sensor Port | Yes |
Transmission | 10R80 |
Transmission Type | Automatic |
UPC | 090127469408 |
California Proposition 65 Chemical Name | Chromium (hexavalent compounds) |
California Proposition 65 Required | Yes |
Part Number | 7o400 |
