HOLLEY SNIPER EFI
SNIPER EFI SHEET METAL FABRICATED INTAKE MANIFOLD GM LS7
Sheet Metal Fabricated Intake Manifold LS7 102mm Throttle Body opening + Fuel Rail Kit Silver with Sniper EFI logo
– Now includes mounting provision for MAP sensor on rear of Intake plenum. Use GM #12592525 or equivalent.
Part # 830041-1
Holley is now offering budget friendly fabricated intake manifolds for LS, Small Block Chevy and Small Block Ford engines in carbureted and EFI versions!
Features:
- Silver finish creates high impact under-hood styling
- 3mm (1/8″) thick T6061 sheet aluminum construction for maximum durability
- 102mm throttle bore opening for increased air flow
- 100% TIG welded for strength and durability
- Includes 3/8″ Fuel rail kits (Sniper logo laser engraved)
- Intake runners with tapered top is designed to increase air velocity and more evenly distribute airflow to all 8 cylinders improving performance and throttle response
- Provision for MAP sensor located on rear of plenum
- Product includes all gaskets and hardware for a hassle-free installation
- The Sniper intake will only accept EV1 style injectors.
| Brand | Holley Sniper EFI |
|---|---|
| Color | Silver |
| Construction | Fabricated |
| Emission Code | 4 |
| Engine | GM LS7 |
| Finish | Silver |
| Front Height | 7.362 inch |
| Fuel System Type | EFI |
| Injector Style Provision | EV1 |
| Manifold Type | Fabricated |
| Product Type | Intake Manifold |
| Rear Height | 6.850 inch |
| Recommended Use | Forced Induction |
| RPM Power Band | 2500-7000 RPM |
| Runner Length | 4.921″ (125mm) |
| Style | EFI |
| Throttle Bore | 102mm |
| Vacuum Ports | (3) 1/8″-28BSPT & (1) 1/4″-19BSPT |
| Warranty | Limited 90 Day |
| UPC | 090127045336 |
| Part Number | 830041-1 |
